DJI | Mavic Mini Drone Fly More Combo

SPECS


MAVIC MINI
Aircraft
Takeoff Weight [1]
249 g / 199 g (JP)
Dimensions
Folded: 140×82×57 mm (L×W×H)
Unfolded: 160×202×55 mm (L×W×H)
Unfolded (with propellers): 245×290×55 mm (L×W×H)
Diagonal Distance
213 mm
Max Ascent Speed
4 m/s (S Mode)
2 m/s (P Mode)
1.5 m/s (C Mode)
Max Descent Speed
3 m/s (S Mode)
1.8 m/s (P Mode)
1 m/s (C Mode)
Max Speed (near sea level, no wind)
13 m/s (S Mode)
8 m/s (P Mode)
4 m/s (C Mode)
Max Service Ceiling Above Sea Level
3000 m
Max Flight Time
30 minutes (measured while flying at 14 kph in windless conditions)
Max Wind Speed Resistance
8 m/s (Scale 4)
Max Tilt Angle
30° (S Mode)
20° (P Mode)
20° (C Mode)
Max Angular Velocity
150°/s (S Mode)
130°/s (P Mode)
30°/s (C Mode)
Operating Temperature Range
0° to 40°C (32° to 104°F)
Operating Frequency
Model MT1SS5: 5.725-5.850 GHz
Model MT1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmission Power (EIRP)
Model MT1SS5
5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)
Model MT1SD25
2.4 GHz: <19 dBm (MIC/CE)
5.8 GHz: <14 dBm (CE)
GNSS
GPS+GLONASS
Hovering Accuracy Range
Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GPS Positioning)
Horizontal: ±0.1 m (with Vision Positioning), ±1.5 m (with GPS Positioning)
Gimbal
Mechanical Range
Tilt: -110° to 35°
Roll: -35° to 35°
Pan: -20° to 20°
Controllable Range
Tilt: -90° to 0° (default setting) -90° to +20° (extended)
Stabilization
3-axis (tilt, roll, pan)
Max Control Speed (tilt)
120°/s
Angular Vibration Range
±0.01°
Sensing System
Downward
Operating Range: 0.5-10 m
Operating Environment
Non-reflective, discernable surfaces
Diffuse reflectivity (>20%)
Adequate lighting (lux>15)
Camera
Sensor
1/2.3” CMOS
Effective Pixels: 12 MP
Lens
FOV: 83°
35 mm Format Equivalent: 24 mm
Aperture: f/2.8
Shooting Range: 1 m to ∞
ISO Range
Video:
100-3200 (Auto)
Photo:
100-1600 (Auto)
100-3200 (Manual)
Shutter Speed
Electronic Shutter: 4-1/8000s
Still Image Size
4:3: 4000×3000
16:9: 4000×2250
Still Photography Modes
Single shot
Interval: 2/3/5/7/10/15/20/30/60 s
Video Resolution
2.7 K: 2720×1530 25/30 p
FHD: 1920×1080 25/30/50/60 p
Max Video Bitrate
40 Mbps
Supported File System
FAT32（≤32 GB）
exFAT（>32 GB）
Photo Format
JPEG
Video Format
MP4 (H.264/MPEG-4 AVC）
Remote Controller & Video Transmission
Operating Frequency
Model MR1SS5: 5.725-5.850 GHz
Model MR1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz
Max Transmission Distance (unobstructed, free of interference)
Model MR1SS5
5.8 GHz: 4000 m (FCC); 2500 m (SRRC)
Model MR1SD25
2.4 GHz: 2000 m (MIC/CE)
5.8 GHz: 500 m (CE)
Operating Temperature Range
0° to 40°C (32° to 104°F)
Transmission Power (EIRP)
Model MR1SS5
5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)
Model MR1SD25
2.4 GHz: <19 dBm (MIC/CE)<br style="box-sizing: b
